Automatic Build Generation for Android / iOS Builds and Uploading to HockeyApp through Script File

By Sathish Kumar Kondi,

Xamarin Automatic Build Generation for Deployment

Xamarin native apps with a single code baseXamarin lets you deliver native Android, iOS, and Windows apps with a single shared .NET code base.

Xamarin tools are available to download with Visual Studio and you can directly create Android, iOS and Windows apps from Visual Studio itself. Most of the common code is written in C#. So you don’t need to be well versed in Java, Objective‐C or Swift to build apps if you already know C#. If you are a beginner, then taking the Xamarin path instead of the conventional learning process can actually teach you app development for more than one platforms. But will you miss out on real native functionality?

The answer to that question is mostly No. The great set of features provided by the entire toolset makes sure you don’t miss out on any functionality. But at some point, where you might want to dive deeper, Xamarin lets you call existing code written in other platform-specific languages such as Java in Android. But that is only when you are building something very specific which cannot be implemented on different platforms.

The below blog explains the process used for the following purposes

  • Generate .APK file for Android through a Batch file
  • Generate .IPA file for iOS through a Batch file
  • Upload .APK file and .IPA file to Hockey App through Batch file.

Pre‐Requisites

  • iOS distribution certificate and mobile provisioning file installed in Mac System
  • Android signing certificate in project folder
  • Xamarin Native or Forms Android and the iOS project developed through Visual Studio 2017
  1. GenerateAPK.sh

    • Create Folder GenerateBuildsFile in your project folder
    • Create a new .sh extension file with “GenerateAPK.sh” name
    • Copy the below script into your .sh file
      #!/bin/bash
      cd ..
      # Change the Path to the Solution Project folder
      SLNPath=$PWD"/"
      # echo $SLNPath
      MyPath=$SLNPath"Droid/"
      cd $MyPath
      AssemblyInfoPath=$MyPath"Properties/AssemblyInfo.cs"
      echo $AssemblyInfoPath
      # /p:AssemblyPath=AssemblyInfoPath
      VersionNumber=$1
      BuildNumber=$2
      # Build the Project in release mode
      MSBuild /t:Clean /p:Configuration=Release
      MSBuild /t:SignAndroidPackage /p:Configuration=Release /p:SetVersion=True /p:VersionNumber=$Versio
      # Path to the Generated Signed APK file
      SignedAPKPath=$MyPath"bin/Release/*Signed.
      apk"
      echo $SignedAPKPath
      #Make a new directory for Saving the builds
      mkdir $SLNPath"Builds"
      # New Path to save the Builds
      NewPath=$SLNPath"Builds"
      echo $NewPath
      mv $SignedAPKPath $NewPath"/<AppName>.apk"
    • This File takes the parameters for Version Number and Build Number from the file and uses MS Build process to clean, build and generate the .apk file
    • Replace “AppName” text with your project name in the file
    • Open the project in Visual Studio 2017 and open properties for Xamarin.Droid project, browse and select the correct keystore file in Android Build Signing properties for release mode
    • Add these lines of code in .Droid.csproj file inside Project Tag, this code uses the version number and build number dynamically
      <Target Name="BeforeBuild" Condition=" $(SetVersion) == true ">
      <XmlPoke XmlInputPath="Properties\AndroidManifest.xml"
      Namespaces="&lt;Namespace Prefix='android'
      Uri='http://schemas.android.com/apk/res/android' /&gt;"
      Query="manifest/@android:versionCode" Value="$(BuildNumber)" />
      <XmlPoke XmlInputPath="Properties\AndroidManifest.xml"
      Namespaces="&lt;Namespace Prefix='android'
      Uri='http://schemas.android.com/apk/res/android' /&gt;"
      Query="manifest/@android:versionName" Value="$(VersionNumber)" />
      </Target>
  2. GenerateIPA.sh

    • Create a new .sh extension file with “GenerateIPA.sh” name, Copy the below content to your sh file
      #!/bin/bash
      cd ..
      # Change the Path to the Solution Project folder
      SLNPath=$PWD"/"
      echo $SLNPath
      # New Path to save the Builds
      NewPath=$SLNPath"Builds"
      echo $NewPath
      cd ..
      SLNPath=$PWD"/"
      echo $SLNPath
      # Navigate to the main SLN Folder
      cd $SLNPath
      VersionNumber=$1
      BuildNumber=$2
      # Build the Project in release mode
      MSBuild /p:Configuration="Release" /p:Platform="iPhone" /p:IpaPackageDir="$NewPath” /t:Clean <ProjectName>.sln
      MSBuild /p:Configuration= "Release" /p:Platform="iPhone" /p:SetVersion=True /p:VersionNumber=$VersionNumber /p:BuildNumber=$BuildNumber /p:IpaPackageDir="$NewPath" /t:Build <ProjectName>.sln
    • This File takes the parameters for Version Number and Build Number from the file and uses MS Build process to clean, build and generate the .ipa file
    • Replace “ProjectName” text with your project name
    • Open your project in Visual Studio 2017, open properties for Xamarin.iOS project and select the Signing Certificate and Provisioning file in iOS Build Signing properties for release mode
    • Add these lines of code in .iOS.csproj file inside Project Tag, this code uses the version number and build number dynamically:
      <Target Name="BeforeBuild" Condition=" $(SetVersion) == true ">
      <XmlPoke XmlInputPath="Info.plist" Query="//dict/key[. = 'CFBundleVersion']/followingsibling::s
      <XmlPoke XmlInputPath="Info.plist" Query="//dict/key[. = 'CFBundleShortVersionString']/following
      </Target>
  3. UploadFile.sh File

    This file contains script to upload the .apk files and .ipa file to HockeyApp with the Hockey App Token provided in BuildsScript File.

    • Create a new .sh extension file with “UploadFile.sh” name. Copy the below script contents to your sh file
      #!/bin/bash
      # locations of various tools
      CURL=curl
      SERVER_ENDPOINT=https://rink.hockeyapp.net/api/2/
      # Put your HockeyApp APP_TOKEN here. Find it in your HockeyApp account settings.
      APP_TOKEN=$1
      # ipa required,
      file data of the .ipa for iOS, .app.zip for OS X, or .apk file for Android
      IPA=$2
      # dsym optional,
      file data of the .dSYM.zip file (iOS and OS X) or mapping.txt (Android);
      # note that the extension has to be .dsym.zip (caseinsensitive)
      for iOS and OS X and the file nam
      DSYM=""
      # notes optional,
      release notes as Textile or Markdown (after 5k characters note are truncated)
      NOTES=$3
      # echo $NOTES
      # notes_type optional,
      type of release notes:
      # 0 for Textile
      # 1 for Markdown
      NOTES_TYPE="0"
      # optional, notify testers (can only be set with fullaccess
      tokens):
      # 0 to not notify testers
      # 1 to notify all testers that can install this app
      # 2 Notify
      all testers
      NOTIFY=$4
      echo $NOTIFY
      # status optional,
      download status (can only be set with fullaccess
      tokens):
      # 1 to not allow users to download the version
      # 2 to make the version available for download
      STATUS="2"
      # strategy optional,
      replace or add build with same build number
      # add to add the build as a new build to even if it has the same build number (default)
      # replace to replace to a build with the same build number
      STRATEGY="replace"
      # tags optional,
      restrict download to commaseparated
      list of tags
      TAGS=""
      # teams optional,
      restrict download to commaseparated
      list of team IDs; example:
      # 12,23,42 with 12, 23, and 42 being the database IDs of your teams
      TEAMS=""
      # users optional,
      restrict download to commaseparated
      list of user IDs; example:
      # 1224,5678 with 1224 and 5678 being the database IDs of your users
      USERS=""
      # mandatory optional,
      set version as mandatory:
      # 0 for not mandatory
      # 1 for mandatory
      MANDATORY=""
      # release_type optional,
      set the release type of the app:
      # 2 for alpha
      # 0 for beta [default]
      # 1 for store
      # 3 for enterprise
      RELEASE_TYPE=""
      # private optional,
      set to true to enable the private download page (default is true)
      PRIVATE=""
      # owner_id optional,
      set to the ID of your organization
      OWNER_ID=""
      # commit_sha optional,
      set to the git commit sha for this build
      COMMIT_SHA=""
      # build_server_url optional,
      set to the URL of the build job on your build server
      BUILD_SERVER_URL=""
      # repository_url optional,
      set to your source repository
      REPOSITORY_URL=""
      usage() {
      echo "Usage: hockeyappuploader.
      sh IPA"
      echo
      }
      verify_tools() {
      # Windows users: this script requires curl. If not installed please get from http://cygwin
      # Check 'curl' tool
      "${CURL}" help
      >/dev/null
      if [ $? ne
      0 ]; then
      echo "Could not run curl tool, please check settings"
      exit 1
      fi
      }
      verify_settings() {
      if [ z
      "${APP_TOKEN}" ]; then
      usage
      echo "Please update APP_TOKEN with your private API key, as noted in the Settings
      exit 1
      fi
      }
      # if [ $# ne
      1 ]; then
      # usage
      # exit 1
      # fi
      # before even going on, make sure all tools work
      verify_tools
      verify_settings
      if [ ! f
      "${IPA}" ]; then
      usage
      echo "Can't find file: ${IPA}"
      exit 2
      fi
      /bin/echo n
      "Uploading ${IPA} to HockeyApp.. "
      JSON=$( "${CURL}" \
      s
      ${SERVER_ENDPOINT}/apps/upload \
      H
      "XHockeyAppToken:
      ${APP_TOKEN}" \
      F
      "ipa=@${IPA}" \
      F
      "dsym=@${DSYM}" \
      F
      "notes=${NOTES}" \
      F
      "notes_type=${NOTES_TYPE}" \
      F
      "notify=${NOTIFY}" \
      F
      "status=${STATUS}" \
      F
      "strategy=${STRATEGY}" \
      F
      "tags=${TAGS}" \
      F
      "teams=${TEAMS}" \
      F
      "users=${USERS}" \
      F
      "mandatory=${MANDATORY}" \
      F
      "release_type=${RELEASE_TYPE}" \
      F
      "private=${PRIVATE}" \
      F
      "owner_id=${OWNER_ID}" \
      F
      "commit_sha=${COMMIT_SHA}" \
      F
      "build_server_url=${BUILD_SERVER_URL}" \
      F
      "repository_url=${REPOSITORY_URL}" \
      )
      URL=$( echo ${JSON} | sed 's/\\\//\//g' | sed n
      's/.*"public_url"\s*:\s*"\([^"]*\)".*/\1/p' )
      if [ z
      "$URL" ]; then
      echo "FAILED!"
      echo
      echo "Build uploaded, but no reply from server. Please contact support@hockeyapp.net"
      exit 1
      fi
      echo "OK!"
      echo
      echo "Build was successfully uploaded to HockeyApp and is available at:"
      echo ${URL}

    • Replace “<ProjectName>” text with your project name
  4. BuildsScript.sh File

    This file internally uses GenerateAPK.sh, GenerateIPA.sh, UploadFile.sh scripts to Generate and upload .apk and .ipa files to HockeyApp. Follow these steps to build the BuildScript.sh File:

    • Create a new .sh extension file with “BuildsScript.sh” name, Copy the below content to your BuildsScript.sh
      #!/bin/bash
      VersionNumber="1.0.0"
      BuildNumber="7"
      # notes optional,
      release notes as Textile or Markdown (after 5k characters note are truncated)
      NOTES="
      Fixed Issue and changed
      Issues related to COff Debit Fixed
      "
      Platform=$1
      ReleaseAndroid=false
      ReleaseiOS=false
      if [ z
      "${Platform}" ]; then
      ReleaseAndroid=true
      ReleaseiOS=true
      fi
      if [ "$Platform" = "android" ] ; then
      ReleaseAndroid=true
      ReleaseiOS=false
      fi
      if [ "$Platform" = "ios" ] ; then
      ReleaseAndroid=false
      ReleaseiOS=true
      fi
      # Put your HockeyApp APP_TOKEN here. Find it in your HockeyApp account settings.
      APP_TOKEN=""
      chmod 777 GenerateAPK.sh
      chmod 777 GenerateIPA.sh
      chmod 777 UploadFile.sh
      cd ..
      # Change the Path to the Solution Project folder
      SLNPath=$PWD"/"
      echo $SLNPath
      cd GenerateBuildsFile
      # Generate Android APK File
      if [ "$ReleaseAndroid" = true ] ; then
      echo 'Generation APK file'
      ./GenerateAPK.sh $VersionNumber $BuildNumber
      fi
      #Generate IOS IPA File
      if [ "$ReleaseiOS" = true ] ; then
      echo 'Generation IPA file'
      ./GenerateIPA.sh $VersionNumber $BuildNumber
      fi
      # New Path to save the Builds
      NewPath=$SLNPath"Builds"
      # echo $NewPath
      BuildsPath=$SLNPath"GenerateBuildsFile"
      # echo $BuildsPath
      cd $BuildsPath
      # optional, notify testers (can only be set with fullaccess
      tokens):
      # 0 to not notify testers
      # 1 to notify all testers that can install this app
      # 2 Notify
      all testers
      NOTIFY="2"
      # Path to the APK File
      # ipa required,
      file data of the .ipa for iOS, .app.zip for OS X, or .apk file for Android
      IPA=$NewPath"/.apk"
      # echo $IPA
      #Upload the Android APK file to Hockey APP
      if [ "$ReleaseAndroid" = true ] ; then
      echo 'Uploading APK file'
      ./UploadFile.sh $APP_TOKEN $IPA "$NOTES" $NOTIFY
      fi
      # Path to the IPA File
      # ipa required,
      file data of the .ipa for iOS, .app.zip for OS X, or .apk file for Android
      IPA=$NewPath"/.iOS.ipa"
      # echo $IPA
      #Upload the IOS file to Hockey APP
      if [ "$ReleaseiOS" = true ] ; then
      echo 'Uploading IPA file'
      ./UploadFile.sh $APP_TOKEN $IPA "$NOTES" $NOTIFY
      fi
    • Replace “<ProjectName>” text with your project name
    • Modify these properties in BuildsScript.sh file
      1. VersionNumber as your required version number (1.0.0)
      2. BuildNumber as your required build number (7)
      3. Notes as your release notes text
      4. APP_TOKEN ‐ Put your HockeyApp APP_TOKEN here. Find it in your HockeyApp account settings
    • Bundle Identifier for Android and iOS project must match with the HockeyApp app identifier
  5. Usage

    In order to generate and upload the builds to HockeyApp, follow these steps:

    1. Open Terminal in your Mac
    2. Navigate to your Project Folder → GenerateBuilds by running this command:
      cd ///GenerateBuildsFile
    3. To Generate and Upload Android .apk file to HockeyApp, Run this command:
      /BuildsScript.sh android
    4. To Generate and Upload iOS .ipa file to HockeyApp, Run this command:
      ./BuildsScript.sh ios
    5. To Generate and Upload Android .apk file and iOS .ipa file to HockeyApp, Run this command:
      ./BuildsScript.sh

Topics: Mobility

Sathish Kumar Kondi

Sathish Kumar Kondi

Senior Engineer - Software Engineering

Subscribe to Email Updates

Authors

Show More

Recent Posts
