IoT Sensor Datasheets
SKU – Rechargeable Sensor Hub
A LTE/CAT-M enabled, multi-use battery-powered smart tracking hub for visibility and compliance
|
Device Features
|
Sensor Capabilities
|
Software/Service
|
Networks
|
| Features | Specifications | |
| Communication | Communication | LTE Cat M1/EGPRS coverage 802.11b/g/n | Bi-directional communications; over-the-air adjustable reporting rate; reporting rate: 15min to 24 hour |
| Location Accuracy | Wi-Fi | 100 meters |
| Cellular | 500 meters | |
| GPS | 3-5 meters | |
| Certification | Industry Certifications | ROHS, CE, PTCRB, FCC Activated upon breaking off tab | Max Output Power is Less than 100mW EIRP |
| Power | Battery Type | Rechargeable l Li-ion battery | Wireless recharging (8 hr recharge time) |
| Operating Parameters | On/off button | Green upon button press for on; Red upon button press for off | Green pulse (Periodic) for charging | |
| Environmental |
Temperature |
-10°C to 65°C | 14°F to 149°F (Storage) | -10°C to 65°C | 14°F to 149°F (Operating) |
|
IP Rating |
IP67 |
|
|
Rugged Construction |
Shock and vibration resistant |
|
| Physical/Design | Dimensions | 5.6” x 3.3” x 0.65” (142 mm x 82 mm x 16.5 mm) |
| Weight | 168g (6 oz) | |
| Sensors |
Motion |
Stationary/Moving after stationary |
| Temperature | NIST traceable; accuracy =/- 0.5C; -40 to 125C min/max threshold | |
| Light | Threshold on/off | |
| Pressure | Flight detection | |
| Shock | Dedicated 3-axis accelerometer 16 G max | |
| Impact | General shock event | |
| Drop | Vertical drop above threshold | |
| Tilt | 90 degrees | |
SKU – Disposable Sensor Hub
SKU – Disposable Sensor Hub
|
Device Features
|
Sensor Capabilities
|
Software/Service
|
Networks
|
| Features | Specifications | |
| Communication | Network Bands | Worldwide LTE Cat M1/Cat NB1/EGPRS coverage 802.11b/g/n |
| Positioning | Positioning Engine | Hybrid Positioning Engine, with locations from A-GPS, visible cell towers and WiFi access points |
| Certification |
Industry Certifications |
ROHS, CE, PTCRB, FCC |
| Power |
Battery Type |
4 Alkaline AAs |
|
Operating Parameters |
Push button to turn on, LED indicates units is on |
|
| Battery Life |
Up to 60 Days of Battery Life |
1 hr (Stationary); 15 min (When in motion) | 5 min temperature logging | 10 sec temperature monitoring (Considering 8hrs of motion per day) |
| Environmental |
Temperature |
-4 to 129°F (-20 to 54°C) Operating | 41 to 86°F (5 to 30°C) Storage |
|
IP Rating |
67 | |
| Physical/ Design |
Dimensions |
5.6” x 2” x 1” (141.2 mm x 49.2 mm x 24.1 mm) |
|
Weight |
5.7 oz (160 g) | |
| Sensors |
Motion |
Accelerometer |
| Temperature | 14°F to 257°F (-10 to +125°C) NIST traceable | |
| Pressure | Flight mode | |
| Light | Package open/close | |
| Tag Reporting | Range | 20m Indoors 80m Outdoors |
| Reporting level | Configurable | |
iNNTACT BLE Sensors
Economical, Smart Sensor Tags for Logging Data on Environmental Conditions and Location
|
Device Features
|
Sensor Capabilities
|
Software/Service
|
|
|
Disclaimer: The above-mentioned BLE sensor is compatible with iNNTACT IoT Gateway devices but are not the property of Innominds. |
||||
| Features | Specifications | |
| Communication | Bluetooth | Requires secure communication with 1204 or 1204V Hub 250 ft (80 meters) line of sight |
| Certification | Industry Certifications |
FAA Compliant, FCC, CE, NIST |
| Power |
Battery Type |
Lithium Primary Coin Cell (Non-replaceable) |
|
Operating Parameters |
Activated upon breaking off tab | Max Output Power is Less than 100mW EIRP | |
| SKUs |
P4B |
Proximity, battery life 24 months (Typical) |
|
E4BL |
Proximity,Temperature, Humidity, Battery Life 9 months (Battery life is subject to use case) |
|
| Environmental |
Temperature |
20°C to 60°C (Operating) | -30°C to 60°C (Storage) |
|
Shock and Vibration |
Resistant | |
| Physical/Design | Dimensions | 1.33” x 2.85” x .19” (33.8 mm x 72 mm x 4.7 mm) |
| Sensors |
Proximity |
|
| Motion | Stationary/Moving after stationary | |
| Temperature (E4BL) | NIST Traceable | Accuracy +/- 0.5C type | Min/Max Threshold (configurable) | |
| Humidity (E4BL) | Accuracy 4% rH (20% to 80% rH) | |
| Line of Sight |
250 ft (80 meters) |
|
| Sensor Logging capable | E4BL - 50 Days, Temperature & Humidity | |
